One air tight side manway stainless steel holding tank for large milk collection
Stainless steel holding tank have excellent corrosion resistance, high strength, long life, etc. the appearance can be manufactured into several varieties, such as set-up type, horizontal type, transportation, mixing, etc.
Usage: Applicable for large milk collection center, or for milk outdoor storage at large milk production plant; also used at other food and pharmacy factory for storage of liquid product.
This equipment is equipped with cleaning system, agitator, sight and view devices, also have attachments of thermometer and level indication meter.
Specifications:
Material: all material used is high quality sus304-2B stainless steel or SUS 316, inner shell δ=3-4mm and out shell δ=2mm and cooling jacket δ=1.5mm;
Structure: cylindrical shape, conical top cover of 15 degree, with skirt base; with PU(Polyurethane) as heat insulation; with cooling dimple pad at tank wall and base.
Volume range: 15,000L-120,000L
Standard attachments
a). One air tight side manhole;
b). One side mounted agitator at the bottom;
c). One PT100 thermometer, temperature range 0~100℃
d). Two CIP cleaning balls;
e). One aseptic sample valve;
f). Anti butterfly and dirt air vent;
g). Product inlet/outlet
h). Cooling medium inlet/outlet;
i). Level sensor;
j). Ladder with circle protection and protection fence at tank top
Technical parameter:
| Model | Effective volume(L) | External diameter(mm) | Total height(mm) | Heat insulation layer(mm) | Diameter of inlet/outlet | Motor Power (kw) | Side agitator speed(rpm) |
| BYCG-15 | 15000 | 2200 | 6500 | 100 | φ51 | 5.5 | 960rpm |
| BYCG-20 | 20000 | 2380 | 7150 | 100 | φ51 | 5.5 | 960rpm |
| BYCG-30 | 30000 | 2700 | 7850 | 100 | φ51 | 5.5 | 960rpm |
| BYCG-50 | 50000 | 3200 | 9200 | 100 | φ51 | 5.5 | 960rpm |
| BYCG-60 | 60000 | 3400 | 9800 | 100 | φ51 | 5.5 | 960rpm |
| BYCG-100 | 100000 | 3620 | 12990 | 100 | φ51 | 5.5×2 | 960rpm |
| BYCG-120 | 120000 | 3700 | 14200 | 100 | φ51 | 5.5×2 | 960rpm |
Other volumes not specified, we could customize as to customers’ requirement.
And we will recommend manufacturing on site for the volumes that more than 120T.
Product Tags:
|
|
200m3 Airtight Stainless Steel Holding Tank Double Layer Structure Images
|
